FQ-RCT02 EXCELLENT LINEARITY 0.2% 3000A/6000A FLEXIBLE ROGOWSKI COIL

fq-rct02_gfuve_3000a_6000a_flexible_rogowski_coil

Request a quote

Download Catalogue/Video

INTRODUCE

The FQ-RCT02 flexible current sensor is an AC current sensor composed of a flexible rogowski coil. The flexible rogowski coil permits measurements on conductors where standard clamp-on sensors cannot be used. In particular, it can be installed in tight spaces, around cable bundles, around wide or large bus bars, or even wrapped around irregular shapes. It is suitable for large current measuring. They combine the benefits of a thin, flexible, clip-around rogowski (sensor) coil with a signal conditioner providing accurate, true RMS measurement, of voltage output 100mV/kA. Models range from 1A to 100,000Arms with an accuracy of 1% of reading. Rated EN61010, 600V CAT IV, 1000V CAT III. Low cost AC current measurement probe designed to plug into digital multimeters, oscilloscopes, power quality analysis and power or harmonic meters. The length of the rogowski coil current sensor can be selected from 40cm to 100cm or more. Fits around large or small conductors. Capable of getting into tight or difficult spaces. Ideal for measuring AC current in a group of conductors.
All of our rogowski coil are strictly comply IEC60044-1, IEC61869-2, ANSI/IEEE C57.13, IEC/EN61010-2-032, IEC/EN 61010-2-031.

FEATURES

Measurement range of 1A to 100KA AC; Frequency 0.1Hz-10MHz bandwidth; Excellent linearity 0.2% for current measurement; Low phase shift for power measurement; Holding wire diameter: φ305mm/190mm/120mm; 128 high times harmonic measurement; 100mV/kA or 85mV/kA or 50mV/kA output signal; No danger from open-circuited secondary; Improved ergonomic design & easy operation; High permeability magnetic material core; Zero power consumption; Conforms to EN 61010, 1000V CAT III; IP68 protection level design; Ø8 screw type flexible rogowski coil; Minimal positional error; Strong anti-interference and good stability; Designed for DMMs, oscilloscopes, recorders, power and harmonic meters; CNAS, UL, CE mark;

APPLIATIONS

Power quality analyzer; Oscilloscope; Power recorders; Multimeter; Power and harmonic meters; Energy meter calibrator; Measuring around cable bundles; Power load monitoring; Data logging/recording; Power monitoring device; Energy sub-meters; Power quality meter; Lightning current measurement; Smart power meter;

OUTLINE DRAWING

PARAMETERS

Electrical parameters
Model		FQ-RCT02-120	FQ-RCT02-190	FQ-RCT02-305
Current range		1A - 100kA
Frequency		10Hz - 10MHz
Output voltage	Rated current	1000A/2000A	2000A/3000A	3000A/6000A
Output voltage	50Hz	100mV/200mV AC	200mV/300mV AC	300mV/600mV AC
Max output		10kA or 100kA
Accuracy		<1% @25°C (45-65Hz)
Phase error		<30' @25°C (45-65Hz)
Output sensitivity		50mV/kA, 85mV/kA, 100mV/kA (50Hz)
Coil section diameter		8mm
Output sensitivity		±2% Max (No Calibration) ±0.5% @25°C (With Calibration)
Linearity error		±0.2% RD
Position sensitivity		±1%
External influence		±1% Max
Bandwidth		0.1Hz - 10MHz(-3dB)
Power supply		/
Lead length		2.5m or 5m
Standard		EN 61010-1, EN 61010-2-032, EN 61010-2-031 IEC60044-1, & IEC61869-2, 1000V CAT III
Weight		150g - 230g
Degree of protection		IP68
Operation temperature		-30°C to +80°C
Storage temperature		-40°C to +90°C
Notes: can be customized current probe according to user requirements!

SELECTION GUIDE

Dimensions(mm)	FQ-RCT02-120	FQ-RCT02-190	FQ-RCT02-305
Window A	120	190	305
Coil OD B	145	205	335
Coil Length C	400	600	1000
Output connection	1. UL2586-ESB 2x24AWG L=150cm (as required) 2. Coax terminated with safety male BNC connector L=250cm (as required) 3. UL2586-ESB 2x24AWG L=150cm (as required) with integrator

POSITION SENSITIVITY

Bus bar Position		Window A of coil (Φmm)			Position error
Bus bar Position		120	190	305	Position error
Φ (cm)		<12.5	<20	<35	<0.5%
Angel (°)		90°~270°			<1%
Radius(cm)	r	<12	<16	<20	<2%
